PRODUCT HIGHLIGHTS
Discover the advanced engineering and precision features that make the XM-MD12 a leader in CNC machining.
Fully Enclosed & Industrial-Grade Design
The machine features a fully enclosed sheet metal structure with a compact and ergonomic layout. The rigid body design ensures safe operation, effective chip protection, and long-term stability in continuous production environments.
12-Axis Configuration for Complex Machining
The machine features a fully enclosed sheet metal structure with a compact and ergonomic layout. The rigid body design ensures safe operation, effective chip protection, and long-term stability in continuous production environments.
High-Performance Spindle System
The spindle adopts dual-row DB7009 angular contact bearings, delivering strong rigidity and high precision at speeds up to 8000 RPM. It is designed for high-speed, high-accuracy, and energy-efficient machining.
Energy-Saving & Environment-Friendly Operation
The machine is driven entirely by servo motors without a hydraulic system, reducing daily energy consumption by over 20 kWh while eliminating oil pollution and lowering maintenance costs.
High-Rigidity T-Type Structure
A reinforced T-type structure with independently designed Z-axis and X/Y axes significantly enhances overall rigidity and feeding stability. This structure is especially suitable for complex multi-axis and heavy-duty machining.
High-Speed Servo Turret Tool Change
Equipped with a servo-driven turret system, the diagonal tool change time is as fast as 1 second. Imported three-piece tooth locking ensures precise positioning, strong clamping force, and excellent long-term reliability.
Precision Linear Guide System
Taiwan HIWIN RGH35 ball screw linear guide rails are used across the machine, providing smooth motion, high rigidity, and stable accuracy during long-term operation.
Internal Structure
The internal structure is designed for high rigidity, stable operation, and long-term reliability, ensuring consistent performance and machining accuracy during continuous production.
